There’s not a whole lot to say here… I mean, they’re GIANT LIGHTSABERS!!

Why, you might ask, would someone make these? WHY NOT?!    Actually, the truth is, a company asked me to make an over the top Star Wars/Christmas themed display, and these were a part of it.  Fortunately, I made a video of the build so I could share with you guys!



They are absolutely ridiculous, but they were one of the most fun projects, and videos, I’ve made in a long time.  I think I might need to spend a little more time with projects that are just senseless fun!

Enjoy!

Here’s what you’ll need:

(purchasing via these affiliate links supports ILTMS)

I gathered some spray paint and black duct tape for decorating.

Screen-Shot-2015-11-12-at-9.50.11-AM

For the handles, I got two 12″ concrete forms.

Screen-Shot-2015-11-12-at-9.50.23-AM

One can of spray paint was more than enough to fully cover both tubes with paint.

Screen-Shot-2015-11-12-at-9.50.35-AM

The “blades” were made from a single sheet of corrugated plastic sheeting.

Screen-Shot-2015-11-12-at-9.51.22-AM

I wrapped them into a tube, and clamped the ends. I predrilled holes along the edge where they overlapped.

Screen-Shot-2015-11-12-at-9.51.48-AM

I drove in some sheet metal screws to hold the tube space.

Screen-Shot-2015-11-12-at-9.51.58-AM

Once the paint was dry, I used black duct tape to decorate the handles.

Screen-Shot-2015-11-12-at-9.52.20-AM

I found that it was easiest to get a straight line by rolling the handle on a table.

Screen-Shot-2015-11-12-at-9.52.34-AM

It’s really easy to make these resemble lightsaber handles with just tape.

Screen-Shot-2015-11-12-at-9.52.53-AM

I made a circular paint mask by tracing the duct tape roll onto some scrap cardboard.

Screen-Shot-2015-11-12-at-9.53.19-AM

I cut out the circle with a utility knife.

Screen-Shot-2015-11-12-at-9.53.34-AM

Using blue tape, I mounted the mask to the handles.

Screen-Shot-2015-11-12-at-9.53.44-AM

A light coat of red spray paint added a big on/off button.

Screen-Shot-2015-11-12-at-9.54.11-AM


For each handle, I cut two 12″ length of 2×4.

Screen-Shot-2015-11-12-at-10.00.23-AM

On the table saw, I ripped these down into 1 1/2″ strips.

Screen-Shot-2015-11-12-at-10.00.51-AM

I also cut some MDF scraps to 12″ long.

Screen-Shot-2015-11-12-at-10.00.59-AM

I put a short bit into my driver, so it would fit inside the “blade” tube.

Screen-Shot-2015-11-12-at-10.01.13-AM

I drove some drywall screws through the plastic, from the inside.

Screen-Shot-2015-11-12-at-10.01.30-AM

These screws attached four 2×4 pieces to the outside of the tube, evenly spaced around it.

Screen-Shot-2015-11-12-at-10.02.24-AM

I removed the bracket from an LED spotlight.

Screen-Shot-2015-11-12-at-10.04.20-AM

I screwed the bracket into the center of the MDF scraps I’d cut earlier.

Screen-Shot-2015-11-12-at-10.04.30-AM

Then I reattached the spotlight to the bracket.

Screen-Shot-2015-11-12-at-10.04.41-AM

The spotlight is adjustable on the bracket, so I faced it straight up.

Screen-Shot-2015-11-12-at-10.04.59-AM

Then I screwed the MDF into the bottom of two opposing 2×4 pieces.

Screen-Shot-2015-11-12-at-10.05.10-AM

The entire blade assembly fit into the handle tube. I slid it in until the 2×4’s were completely hidden.

Screen-Shot-2015-11-12-at-10.05.25-AM

I drove drywall screws through the outside, into the 2×4 using 2″ screws.  Each 2×4 got at least two screws.

Screen-Shot-2015-11-12-at-10.05.33-AM

The lightsabers are way more rigid than I expected.. in fact, you can fight with them 🙂

Screen-Shot-2015-11-12-at-10.05.54-AM

Watch the video above to see them in action!

Screen-Shot-2015-11-12-at-10.06.48-AM
